ModelEngineCastings.com

Dedicated to Classic Engine Casting Kits

We are in the process of reconditioning several Original engine patterns so we can continue to produce these classic engine casting kits. Some patterns are 30 years old and need TLC to produce the best castings possible so, please, be patient. Our goal is to provide the best casting kits and plan sets available for these "Classic Engines" from the past.
                  All rights reserved



Contact us
 ===================================================================================      LITTLE ANGEL
Bob Shores Engine
LITTLE ANGEL DRAWINGS by Bob Shores
(16) 11x17drawings, (11) 8.5x11 pages of construction tips


1-cylinder water-cooled, 4-cycle, governor-controlled gas engine with a bore and stroke of 1/2 inch

Constructed from bar stock- not difficult to build


These Plans Built Engine Can be built on  a Sherline Lathe and Sherline Mill

Height                         3.1”                                        Displacement               .098    typical
Width                          3.5”                                        Flywheel                        2.5” OD
Length                        4.8”                                        Ignition                          5 degrees BTDC
Bore                           .500    to .620                         Spark plug                    1/4-32
Stroke                        .500                                        Spark plug gap            .015
Cylinder Liner           Cast iron                                Fuel                              gasoline
Piston                        Cast iron

====================================================================================                                                SILVER ANGEL
Bob Shores Engine








SILVER ANGEL DRAWINGS by Bob Shores
(15) 11x17 drawings, (18) 8.5x11 pages of construction tips

1 cylinder, air-cooled, 4 cycle,  fly-ball governed gas engine with a bore and stroke of 3/4 inch

  Constructed from bar stock- not difficult to build.


Height                             5.62”                                 Displacement                   .3 cubic inch
Width                              3.75”                                 Flywheel                            3.75 inch OD
Length                            4.3”                                   Ignition                              5 degrees BTDC
Bore                                750”                                  Spark plug                        1/4-32
Stroke                             750”                                  Spark plug gap                 .015
Cylinder Liner                Cast Iron                          Fuel                                   gas/oil mix
Piston                             Aluminum
==============================================================
